Investing in Compact Solar Water Heater for Residential Hot Water Needs

Like most homeowners, you must be looking for a highly affordable and efficient solar water heating system for residential hot water requirements. What about investing in a compact solar water heater for your home! It uses the same high-performance TZ58 1800 SunRain solar collectors which are available on all Northern Lights solar water heating systems.

This compact water heater is specifically engineered for residential hot water purposes. It comes with a storage tank and heat pipe vacuum tubes. This unit is SRCC certified to accommodate the hot water requirements of a family with four to five people which requires an 80-galloon stainless steel heavily insulated water tank.

When it comes to its installation, normally it should be based on a southern facing roof or mounted on the ground with a 45-degree frame. Remember that, the connection and installation of this system are easy. One end of the system connects to the cold water intake of your home whereas the hot water supply to the other end. The storage tank contains heat pipes which comprise 30 tubes.

The water gets heated by transferring energy from the vacuum tubes to heat pipes and the potable water directly. When water gets hot, it rises to the top part of the tank where it starts supplying hot water for the household.

This solar water heater is a highly efficient and maintenance-free system. It features a vacuum tube with a heat pipe and an internally sealed heat exchanger. You won’t need to get worried about the leakage when the tube gets damaged. When you find a broken tube, you should simply replace it with a new one and the system continues working without one damaged tube.

What are the Main Benefits of a Compact Solar Water Heater?

This system doesn’t require electricity.

This water heater is a pressurized system that doesn’t contain pumps. The water moves throughout the system by using the pressure from the municipal water supply. As soon as you open the hot water faucet, the hot water from the storage tank flows outside and cold water flows inside the tank to be heated by using the solar evacuated tubes.

This system doesn’t heat excessively.

The system features a built-in air release valve, temperature, and pressure valve which opens at 90C or 194F. When the system gets hot, it will vent off the excess amount of heat.

This system is made from stainless steel.

Both the inner and outer tanks of the compact solar water heater are made from stainless steel which prevents rusting.

This system is highly affordable.

This system is only slightly more than an ordinary water tank. The life expectancy is nearly double as it doesn’t contain any heating element or gas burner which will fail eventually. In addition, you will take advantage of the 30% federal tax credit and state tax credits that apply to the solar water heating system.

In addition, you won’t need a professional solar installer for the installation. It can be installed quickly by the homeowner or a general contractor. Get ready to receive payback from the compact solar water heater within one to two years.

Bottom Line –

Do you want to learn more about the compact solar water heater? Feel free to contact Northern Lights Solar Tubs at +1 (800) 317-9054.

How Does Solar Pool Water Heating System Work?

Most pool owners are very much aware of the benefits and cost savings of using a solar water heating system for the pool. They often use their pools on a seasonal basis. This means the pools are used during the summer season.

However, investing in solar pool water heating systems can bring great benefits for pool owners. Solar pool heaters can be integrated allowing pool owners to use them in the summer so that they can supply heat to the pool whereas they provide home and space heating as well as residential hot water during winter.

How do solar pool heaters work?

When it comes to buying solar pool heating systems, you should look no further than Northern Lights solar pool heater. Unlike other heating systems, these heaters use a closed-loop system. This means the pool pump pushes water up against gravity which causes excessive wear on the pump and increases the operational cost by up to 30%.

The solar pool heating system separates the heating fluid and pool water through a heat exchanger. A small amount of water or glycol during freezing climates is circulated throughout the solar vacuum tubes at a rate of 0.75-1.25 GPM. They ensure solar energy absorption through the advanced solar evacuated tubes and transfer the energy to the pool through the heat exchanger.

The high flow pool heat exchanger puts very little resistance on the pool pump which allows the system to work at its capacity. Rest assured that, the chlorinated pool water won’t get in contact with the solar system which ensures prolonged life and maximum ROI by up to five times of any ordinary pool heater.

The Northern Lights advanced solar pool heaters are considered more efficient. All they need is to start to turn on providing heat as soon as the sun rises in the morning. For its operation, it doesn’t require direct sunlight. Even in light rain, your solar pool will deliver heat energy to the pool.

A digital controller helps in maximizing solar energy output and has safety features like freeze protection, holiday cooling mode and advanced energy monitoring which will let you know your daily savings. You can get to know the real-time performance and data history on your PC or smartphone through the Free Resol VBus.net as the system can be able to transmit data to the internet.

A highly efficient solar heat exchanger helps in transferring heat between the pools. If you have a saltwater pool or high chlorinated pool, it’s recommended to use a titanium heat exchanger. It will last much longer and won’t get affected by pool chemicals. These solar pool heat exchangers are specifically designed for the application of pool flow rates that can be as high as 50 GPM.

Do you want to learn more about solar pool water heating systems? Feel free to contact Northern Lights Solar Tubs as soon as possible at +1 (800) 317-9054.

What Makes Solar Hot Water Heaters Good Investment?

Over the few years, solar-powered systems have garnered more popularity and recognition among homeowners and business owners. Currently, everyone is looking to use solar energy and take advantage of more savings and efficiency every month.

Now, you’re considering solar water heaters for your home and business. You’re certainly not alone. Most homeowners and local businesses are thinking about the same. Is it a good investment? Take a look at the post and know how it can help you for residential and commercial heating purposes.

How do Solar Water Heaters Work?

A solar water heater has two important components i.e. storage tank and a solar collector. There are two main types of solar hot water systems including an active system that uses a circulating pump and controls and a passive system that doesn’t.

An active solar water heater includes the following options:

Direct Circulation Systems –

These units pump out the residential water through the solar collector and directly into the home. They work optimally in warm climates.

Indirect Circulation Systems –

These systems use non-freezing, heat transfer liquid through a solar collector and heat exchanger. After that, the heated water flows through the pipes of the home. They are ideal for cold climates.

A passive solar water heater includes the followings:

Integral Collector-Storage System – This passive system works well in areas where the temperature rarely goes below freezing. They make a perfect addition to homes for hot water needs during the daytime or evening.

Thermosiphon System –

In this water heating system, water flows directly through the system as the warm water goes to the surface and cool water sinks. The collector needed to be installed directly below the storage tank, making sure that warm water rises perfectly. This system is reliable and is professionally designed as well as installed to ensure optimal performance.

Why Do You Consider Solar Hot Water Heaters?

Now it’s time to discuss the advantages of a solar water heater. You’ve been likely waiting to know about them. The main reasons behind investing in this system are the main deciding factors for homeowners and business owners.

• You’ve accessibility to an abundant amount of free energy.
• Solar thermal panels need less space as just two to three panels are required for every home.
• A solar water heating system is considered a more efficient unit with around 80% radiation turns into heat energy.
• Solar panels are affordable to install.

• By getting this system installed on your premise, you’ll be able to save more on your monthly water and energy bills.
• With a solar hot water heating system, you can be able to minimize your carbon footprint extensively.
• You can take advantage of government incentives and tax savings depending on the area and your solar energy efficiency.

Bottom Line –

Obviously, with such incredible advantages, a solar water heater requires maintenance annually. A solar professional must be chosen to handle the routine maintenance needs. The system may require work on the pump and an anti-freeze top-up occasionally.

When it comes to investing in solar water heaters, you should look no further than Northern Lights Solar Tubs. For more information about our products and their features, give us a call now at +1 (800) 317-9054.
